Benefits of Emulsion Polymers for Elastomeric Roofs

Companies that design roof coatings are in a constant battle with the elements when formulating a coating that can stand up to constant exposure to sunlight, extreme temperature swings, and water damage.

By taking knowledge from other industries, roofing companies have historically tried to use both waterborne house paints and caulking to protect roofs. It wasn’t until the 1970s that elastomeric roof coatings were developed to specifically protect roofs from the elements. Many of the elastomeric roof coatings on the market are formulated with acrylic and styrene-acrylic water based emulsions, which add specific performance characteristics required.

What is an Elastomeric Roof Coating?

An elastomeric roof coating is a liquid that looks a lot like house paint that can be sprayed or rolled on both newly installed and previously existing roofs. The roof needs to be flat or low sloped, dry, and it is applied in a temperature range of 41° to 95°F (5° to 35°C).

While it looks a lot like house paint and it has the same viscosity, the performance properties of elastomeric roof coating are quite different from house paint. One major difference is that elastomeric roof coatings are, as the name implies, more elastic which gives the coating the ability to expand and contract. This versatility can make it very durable during temperature changes because it expands in the heat and it contracts in the cold, meaning it is less likely to crack or break when the temperature changes.

Another major difference is that elastomeric roof coatings are applied in thicker films than house paint. A layer of house paint has a dry film thickness of 3 dry mils whereas elastomeric roofing applications are usually have a dry film thickness of 18 to 20 dry mils and high quality layers can be up to 30 dry mils.

What Performance Requirements Should an Elastomeric Roof Coating Have?

One of the most important requirements of elastomeric roof coating is that they require excellent exterior durability. On top of changes in temperatures and natural elements such as snow and rain, roofs can also be affected by humidity fluctuations, seismic expansion, wind uplift and the vibrations of the building. Additionally, roofs also have to be able to deal with the occasional foot traffic. In order to handle all of those unique variables, elastomeric roof coatings needs to be flexible, yet durable at the same time.

Another requirement that is important with elastomeric roof coatings is reflectivity from both infrared and ultraviolet rays. Elastomeric roof coatings are most often pigmented white or light colors to maximize the amount of solar radiation that is reflect, with high performance coatings reflecting 80% or more of the sun’s radiation. The reflectivity of the coating helps to keep the building cooler, which can reduce energy costs. Because of this requirement, elastomeric roof coatings also need excellent dirt pickup resistance in order to keep the coating white. The cooling effects of the coating would be diminished any time dirt accumulates occurs.

Selecting a Water-Based Emulsion Polymer for an Elastomeric Roof Coating

Many elastomeric roof coatings are formulated with all acrylic or styrene-acrylic water based emulsion polymers. A 100% acrylic or styrene-acrylic emulsions will provide several benefits to help formulators develop high-performance elastomeric roof coatings.

Emulsion polymers are able to provide the roof coating with better adhesion to a variety of substrates, low temperature flexibility, tear resistance, minimal water absorption, and dirt pick up resistance.

Designing Sturdy, Long-Lasting Roofing

Water-based emulsion polymers are ideal for custom-designed elastomers for roofing applications. Mallard Creek Polymers produces a range of emulsion polymer roof coatings for white roof applications, including the new Rovene® 6120 all-acrylic emulsion polymer and Rovene® 6119, 6121, and 6124 styrene-acrylic emulsions. We also offer a range of styrene-butadiene-based products for roof primers.

Rovene® 6120 meets ASTM 6083 Type I standards, the “Standard Specification for Liquid Applied Acrylic Coating Used In Roofing.” It was developed to help contractors and engineers distinguish among acrylic roof coating products. This standard requires that coating material retain its physical and chemical properties down to -26°F (-32.2°) for Type I products, and -10°F (-23°C) for Type II products.

To learn more about our acrylic and styrene acrylic water based emulsions for the elastomeric roof coating market, please visit our applications page.

In addition to our branded products, we can also create unique emulsion polymer coatings tailored to virtually any need. Mallard Creek Polymers scientists can work with your formulation team to develop a solution that meets your requirements. Contact us today to explore how we can start working together.
